Troubleshooting
12-49
12
Conveyor Section
1 Open the front cover 1 and 2.
2 Open the conveyor guide (D7) and remove the
jammed paper.
3 Turn feed knob D5 until the jammed paper is in a
location where it is easy to remove.
If there is no paper jam in the conveyor guide (D7),
proceed to the following step.
4 Close the conveyor guide (D7).
5 Open the conveyor guide (D8) and remove the
jammed paper.
6 Close the conveyor guide (D8).
7 Remove the paper jammed in the center folding
unit.
8 Close the front cover 1 and 2.
To Next Page
