V-TEK PT-55 - Carriage Assembly

D291308.4f.fm Carriage Assembly Details
Chapter 1: Getting Started 5
Carriage Assembly Details
A. Idler Wheel
B. Calibration Jig
C. Carriage Front Track Guide
D. Sprocket Wheel
E. Track Adjustment Knob
F. Carriage Clamp (remove before operation)
Figure 1.5
C
D
A
B
E
F
