Syntax Description
Example:
system
Device Name : HMDW110
Copyright : Copyright (c) Vaisala Oyj 2017. All
rights reserved.
SW Name : HMP113
SW date : 2018-01-03
SW version : 2.2.3 HMDW
HW version :
Table 11 Time Command
Syntax Description
time<cr> Show transmitter uptime (time since last reset)
in hh:mm:ss.
Example:
time
Time : 00:54:51
6.6 Serial Line Output and Communication
6.6.1 Measurement Output
Table 12 Send Command
Syntax Description
send<cr> Output a single measurement message.
send [aaa]<cr> Output a single measurement message from the
device with the defined address:
aaa = address of target device, range 0...255.
Example:
send 5T= 22.8 'C RH= 39.8 %RH Td= 8.4 'C Tw= 14.6 'C h= 40.5 kJ/kg
Chapter 6 – Using Service Port With Terminal Application
39
