3.13 Three-point linkage
7
1
2
5
4
3
6
GUID-788CBEF8-1508-4F67-A0EC-EC02A9C973C9
1. Top link
2. Lift link
3. Hydraulic levelling link (optional) or Lift link (optional)
4. Levelling screw
5. Side limiter
6. Automatic side limiter (optional)
7. Lower links
3. Operation
- 179 -
