3.7 Power outlets
3.7.1 Lighter and power outlets
A lighter socket and power outlets provides an output of 12 V DC; 10 A at a
maximum.
2
3
1
GUID-47FEE990-FDCD-4ACB-A4F0-83A0544070F7
1. Lighter
2. Power outlet on the front console (optional)
3. Power outlet on the right-hand side (optional)
3.7.2 Using the two-pin current socket and power switch
A 2-pin current socket provides an output of 12 V DC; 10 A at a maximum.
1
2
3
4
GUID-E202B646-103D-4035-9A74-E95E868A9D26
1. Power switch
2. 2-pin current socket
3. 2-pin current socket
4. Power outlet
The 2–pin current socket on the right hand side is active when the main power is
on.
