Valtra T144 - Adjusting Standard Mirrors; Adjusting Optional Mirrors

• Set the steering wheel rake.
• Press the locking pedal down.
• Adjust the steering wheel rake to the desired position.
• Release the pedal.
3.2.4 Adjusting standard mirrors
You can adjust the position of the standard mirrors manually.
1
GUID-84D4C889-6DC1-407F-86DA-FFD8196A71C1
1. Locking device of the mirror support
1. Loosen the locking device of the mirror support.
2. Adjust the mirror position.
3. Tighten the locking device.
3.2.5 Adjusting optional mirrors
You can adjust the position of the optional mirrors electrically.
1
L R
2
GUID-7737973C-BFC2-4F4C-971A-C6793957F5FC
1. Mirror adjustment
2. Telescopic mirror adjustment
3. Operation
- 68 -
