Valtra T144 - Changing the Hydraulic Pick-Up Hitch Implement

3.21.5.2 Changing the Hydraulic pick-up hitch implement
You can change the Hydraulic pick-up hitch implement. When the trailer hitch or
drawbar is not in use, you can fasten it to the bracket on the rear side.
2
1
GUID-C5A77E24-A630-4327-923E-945C6CA1CAF0
1. Locking pin
2. Locking ring
1. Lower down and extend the towing device.
2. Raise the towing device to the locking position.
3. Remove the locking ring.
4. Remove the locking pin by pulling.
Support the pick-up hitch implement while removing the locking pin.
5. Pull out the pick-up hitch implement.
6. Attach the pick-up hitch implement.
7. Attach the locking ring.
8. Retract the towing device.
3. Operation
- 236 -
