2.6.5 Other controls
1
2
3
4
5
6
7
8
9
10
GUID-5C89BBA1-A7F1-4194-BBF7-6038C3690154
1. Power outlet (optional)
2. 3-pin current socket
3. 3-pin current socket (optional)
4. ISOBUS terminal connector (optional)
5. ISOBUS bus extension connectors (behind the cover; optional)
6. Implement signal connector (optional)
7. Power switch for 2-pin current socket
8. 2-pin current socket (controlled by power switch)
9. 2-pin current socket
10. Indicator light for implement signal connection (optional)
2.6.6 Main power emergency button
1
2
3
GUID-662324B9-8FB4-4FF7-BEDB-61435F936ACF
1. Main power emergency button
2. Main power on (green light)
3. Main power off (red light)
2. Instruments and controls
- 48 -
