Valtra T144 - Adjusting the Kick-Out Pressure

1
2
GUID-332E3BF9-A9A9-4114-9E6D-26D1DA9C7701
1. Flow control adjustment knob in the cab (optional)
2. Flow control adjustment knob on the valve (optional)
• To increase the oil flow in the valve, rotate the flow control adjustment knob
counterclockwise.
Adjust the flow control only when the control lever is in the middle position.
• To decrease the oil flow in the valve, rotate the flow control adjustment knob
clockwise.
3.14.1.2 Adjusting the kick-out pressure
You can adjust the kick-out pressure between 100-200 bar.
1
GUID-3B777F45-275E-474E-B21F-8A38AC90B827
1. Kick-out pressure adjustment screw
3. Operation
- 193 -
