3.21.7.2 Attaching to the mechanical jaw
You can attach a trailer to the mechanical jaw using the coupling lever.
1
2
3
GUID-6FFF7AB1-633F-4DD9-8879-1FDDE5F3390B
1. Ring
2. Coupling lever
3. Towing pin
1. Pull up the ring at the top of the coupling lever to lift up the towing pin.
WARNING: After attaching the trailer, check that the towing pin is
completely down and locked.
3. Operation
- 241 -
