2.6.2 Linkage
2.6.2.1 Rear linkage
AUTO
CONTROL
STOP
3
4
5
6
7
12
13
8
11
10
9
1
2
GUID-03D8F571-4616-40EC-A8C8-6AA42E34A58F
1. Lowering indicator light
2. Lifting indicator light
3. Diagnostic light
4. Lowering speed selector
5. Max lifting height selector
6. Draft control selector
7. Lifting/lowering switch
8. Trailer hitch release lever (optional)
9. Position control knob
10. Lift/stop/lower switch
11. Override button for position control knob
12. Drive balance control light
13. Drive balance control knob
2.6.2.2 Front linkage
The front linkage is optional.
Connected to rear valves:
