• When engaging the PTO and the attached implement allows it, wait
approximately 5 seconds until the clutch of the PTO shaft is totally engaged
before loading it.
3.17.2 Rear power take-off
You can use power take-off (PTO) to transmit power from the tractor to an
implement.
The PTO shaft is a splined driveshaft that is easily connected and disconnected.
The rear power take-off controls are the following:
GUID-D287B617-3F74-4837-B01A-3B80E76C7543
1. Switch for rear PTO
2. Button for rear PTO automatic start/stop
3. Speed control knob for rear PTO
The rear PTO on/off push button on the rear mudguard is optional:
3. Operation
- 205 -
