Valtra T144 - Using Auto-Guide

• Electrohydraulic steering valve
• A bracket for automated steering system control unit (on the roof)
• Auto-Guide receiver on/off button
• Auto-Guide steering valve on/off button
• Auto-Guide remote activation button
3.20.1 Using Auto-Guide
Before Auto-Guide 3000 steering system can be used and the automatic steering
activated, the receiver and the steering valve must be turned on. Refer to the
Auto-Guide 3000 user manual for more information on timer settings of the
receiver.
1
2
AUTO
3
GUID-B452AF8F-3511-40EF-A94F-4B5F7009A1A8
1. Auto-Guide steering valve on/off button
2. Auto-Guide receiver on/off button
3. Auto-Guide remote activation button
3. Operation
- 224 -
