Valtra T144 - Air Conditioning Controls; Automatic Air Conditioning and Additional Heater Controls; Manual Air Conditioning and Additional Heater Controls

2.12 Air conditioning controls
2.12.1 Automatic air conditioning and additional heater controls
The automatic air conditioning and additional heater system is optional.
AUTO
AUTO
°
C
1
2
4
5
3
6
7
GUID-DDF9F4A0-689E-45E8-B4AA-5455ED35A00D
1. Fan speed control knob (selection OFF/Auto/Manual)
2. Defrost
3. Display
4. Air conditioning ON/OFF
5. Temperature control knob
6. Additional heater fan speed decrease (selection Manual/OFF/Auto)
7. Additional heater fan speed increase (selection ON/Manual)
2.12.2 Manual air conditioning and additional heater controls
The manual air conditioning and additional heater system is optional.
1
2
3
4
GUID-A6F90B40-8A1F-47EE-8492-6E97052B878E
1. OFF/Fan speed control knob
2. Air conditioning ON/OFF
3. Additional heater OFF/fan speed control knob
4. Temperature control knob
2. Instruments and controls
- 54 -
