Inspect unit for oil leaks or
damage
• • ••••
Visually note any leaks or evidence of leaks around the
compressor unit and hose connections. Tighten any
loose connection point where needed. Repair or
replace any damaged part.
9
Inspect cooler fins (both
engine and compressor) for
contamination)
• • ••••
Clean or clear as necessary. Refer to Section 6.5.9.5,
Engine Cooler Maintenance for engine cooler
procedure.
10
Inspect ventilation areas and
surroundings
• • ••••
Ensure ventilation areas and surroundings are not
blocked or clogged with debris. Clean or clear as
necessary.
11
Clean and inspect engine air
filter
• ••••
Consult Section 6.5.9.1, Engine Air Filter
Maintenance.
12
Clean and inspect
compressor air filter
• ••••
Consult Section 6.5.1, Compressor Air Filter.
13
Check/clean all external parts
of compressor and engine
• • ••••
A daily visual inspection will help to prevent dirt and
debris build-up, which can affect machine operation.
When cleaning external parts, always wait for machine
surfaces to cool down before wiping off.
14
Inspect serpentine welder
generator drive belt for wear,
damage or excessive
cracking
••••
Ensure that drive belts are in satisfactory operating
condition, and are tensioned adequately. Should a belt
need to be replaced, consult Sections 6.5.7.8 through
6.5.7.10 for generator drive belt procedures.
15
Check battery cables and
connections
•••
Clean and tighten as necessary. Replace any worn
cables.
6.3 MAINTENANCE SCHEDULE TABLE
INTERVALS
BREAK-
IN
PERIOD
MAINTENANCE SCHEDULE
Hourly or Calendar Period - whichever
comes first
NOTE
First 20
Hours of
Operation
After 8
Hours or
Daily
After 40
Hours or
Weekly
Every 100
Hours or
One Year
Every 200
Hours
After 600
Hours
After 1000
Hours
If working in dusty or dirty conditions, reduce the
recommended time intervals between servicing by
half for engine and compressor oil change, and
engine and compressor filter servicing.
KEY TASK DESCRIPTION
ACTION TO TAKE
Continued on next page
