2.6 Adjusting the Magic Angle
01-999162-00 C0402 VNMR 6.1C User Guide: Solid-State NMR 34
Figure 7. FID Display of KBr on Angle
Figure 8. FID Display of KBr 1/2 Turn Off Angle
Figure 9. Typical Hexamethylbenzene (HMB) Spectrum
20 0 -20406080100120140160180200
ppm
HMB Aromatic Carbons
HMB
Methyl Carbons
