VAT 642 Series - Close Valve; Open Valve; Position Control

OPERATION
Series
642
74/107 Edition 2017-11-24 813316EB
5.2 Close valve
Local operation:
(‘Control View’, ‘Control Performance
Analyzer’ or ‘Service Box 2‘)
Remote operation:
(Refer to chapter «OUTPUT Buffer» > «CONTROL
MODE SETPOINT» for details)
Push CLOSE button
1. «OUTPUT Buffer» > «CONTROL MODE
SETPOINT»
2. Select [Close] (value = 3)
5.3 Open valve
Local operation:
(‘Control View’, ‘Control Performance
Analyzer’ or ‘Service Box 2‘)
Remote operation:
(Refer to chapter «OUTPUT Buffer» > «CONTROL
MODE SETPOINT» for details)
Push OPEN button
1. «OUTUT Buffer» > «CONTROL MODE
SETPOINT»
2. Select [Open] (value = 4)
5.4 Position control
The valve position is directly controlled according to the position setpoint.
Local operation:
(‘Control View’, ‘Control Performance
Analyzer’ or ‘Service Box 2‘)
Remote operation:
(Refer to chapter «OUTPUT Buffer» > «POSITION
SETPOINT» for details)
Select or enter position setpoint
1. In «OUTPUT Buffer» > « POSITION SETPOINT»
2. Select a valid value
3. In «OUTPUT Buffer» > «CONTROL MODE
SETPOINT»
4. Select [Position] (value = 2)
