1. Introduction
6 PaX-i Plus / Insight Installation Manual
Installation Site
 The PC monitor, emergency cut off switch and X-ray Exposure
Switch should be installed in the vicinity of the operator so that
he or she can manage them simultaneously in an emergency.
 Proper shielding of the room is essential: Since these
requirements vary depending on the country, it is the installer’s
responsibilities to verify that all applicable radiation safety
requirements are met.
 This equipment should not be installed in the immediate vicinity
of other devices.
 Do not install the equipment in an area that is exposed to
strong electromagnetic fields.
 Do not install this system in an area where there is the risk of
an explosion.
 The electrical installation of this system shall comply with all
local code requirements for electro-medical systems: IEC
60364-7-710:2002.
 It is strongly recommended that a UPS be installed at the same
time as the equipment.
 The equipment, PC, and all peripheral devices must be well
grounded.
Warnings Regarding X-ray Radiation
 Failure to install this equipment in an approved location may be
dangerous to the patient and operator.
 Stationary radiation shielding must be installed to protect the
operator from radiation.
 The X-ray system may cause injury to the patient if improperly
used. Obey all federal and municipal standards regarding
radiation safety.
 When exposing the patient to the X-ray, the operator must be
behind a protective wall or take other protective actions. The
operator should remain at least 2 m (7 feet) away from the X-ray
when pressing the Exposure Switch and observe the patient
and capture-progression.
 Operators must provide protective clothing to the patient before
X-ray capturing. Pregnant women must consult with a doctor
prior to being exposed to an X-ray.
