5. Installing the Equipment: Wall Mount
66 PaX-i Plus / Insight Installation Manual
Marking Points on the Floor
1. Put the align plate on the floor near the wall where the equipment should be installed
as shown in the figure.
Alignmnet
Plate
(Part No. 4)
2. Mark 6 anchor bolts holes on the floor.
Marker n/a
