Vatech PaX-i3D User Manual

PaX-i3D Green (PHT-60CFO) User Manual
60
4 Software Overview
FOV & Examination Positioning
FOV Size (mm) Vertical Position
Horizontal Position
Right Center Left
50 X 50
Mx. O
A specic tooth selectable
Occl. X
Mn. O
TMJ X
80 X 50
80 X 80
100 x 80
Mx. O O O
Occl. O O O
Mn. O O O
TMJ O O O
120 X 90
Mx. X O X
Occl. X O X
Mn. X O X
TMJ X X X
150 X 150
Mx. X O X
Occl. X O X
Mn. X O X
TMJ X X X
160 X 100
Mx. X O X
Occl. X O X
Mn. X O X
TMJ X X X
Image Reconstruction Time
Xmaru1215CF Master Plus
FOV (mm)
Voxel
Size
Reconstruction Time (s)
File Size
(MB)
High Resolution Mode
(Scan Time: 9.0 s)
Green Mode
(Scan Time: 5.9 s)
MAR
Skip
MAR
Apply
MAR
Skip
MAR
Apply
50 x 50
0.08 48 102 41 84 482
0.12 24 53 21 41 137
80 x 50
0.12 39 100 33 77 358
0.20 19 47 15 36 77
80 x 80
0.12 63 145 53 118 579
0.20 30 63 24 49 122
100 x 80
0.12 87 206 74 167 922
0.20 32 74 26 56 191
[PI3DG_130U_44A_en]User Guide.indd 60 2016-05-24 오후 4:18:42
