Initial Setup Of The Console Using Workflow Wizard Setup>Pumps and Lines>PLLD
43
Setup>Pumps and Lines>PLLD
0.2 gph (0.76lph) Line Leak Test
Touch to select the scheduling frequency of the 0.2 gph (0.76lph) periodic
tests:
Disabled - No manual, repetitive, or monthly 0.2 gph (0.76lph) testing is
allowed. This is the default.
Repetitive - After a dispense, a 3.0 gph (11.3lph) test is run, followed by a
0.2 gph (0.76lph) test. The test blockout period (the Precision Test Delay
in “Setup>Pumps and Lines>All PLLD”) is then observed. Following the
test blockout period, the test sequence repeats after the next dispense.
NOTE: If the 0.1 gph (0.3 lph) test is set for
Repetitive, this test must also
be set to Repetitive. This selection also enables manual 0.2 gph (0.76lph)
tests to run when manually started.
Monthly - The test is scheduled at the beginning of a new month and
remains scheduled until a test is passed.
Manual - 0.2 gph (0.76lph) tests run only when manually started in Diagnos-
tics>PLLD>Manual Tests
0.1 gph (0.38lph) Line Leak Test
Touch to select the scheduling frequency of the 0.1 gph (0.38lph) precision
tests.
Disabled - No manual or automatic 0.1 gph (0.3 lph) testing is allowed. This
is the default.
Repetitive - After a dispense, a 3.0 gph (11.3lph) test is run, a 0.2 gph
(0.76lph) test is run, followed by the 0.1 gph (0.38lph) test. The test blockout
period (the Precision Test Delay in “Setup>Pumps and Lines>All PLLD”)
is then observed. Following the test blockout period, the test sequence
repeats after the next dispense. This selection also enables manual 0.1 gph
(0.38lph) testing tests to run when manually started.
Auto - The 0.1 gph (0.38lph) test is automatically scheduled ro tun 6 months
after the last passed 0.1 gph (0.38lph) test. This setting also gives you the
option to run the Passive 0.1 gph (0.38lph) Line Leak Test.
Manual - 0.1 gph (0.38lph) test runs only when manually started in Diagnos-
tics>PLLD>Manual Tests.
Passive 0.1 gph (0.38lph) Line Leak Test
[only available if the pipe type is user-defined and the 0.1 gph (0.38lph) Line
Leak Test is set to Auto].
Enables a 0.1 gph (0.38lph) test to run after a passed 0.2 gph (0.76lph) test
without the 0.1 gph (0.38lph) test being actively scheduled. If the 0.1 gph
(0.38lph) test also passes, you are notified in Diagnostics>PLLD> 0.1 GPH
Tests. If it fails, there is no notification of the passive 0.1 gph (0.38lph) test.
Allowable selections: Yes, No (default is No).
Shutdown Rate
The line is shut down if a specified or less precise PLLD test fails. For exam-
ple, if you set the shutdown rate for 0.2 gph (0.76lph), the line will shut down
if it fails both the 3.0 gph (11.3lph) test and the 0.2 gph (0.76lph) test.
Allowable selections: 3.0 gph (11.3lph), 0.2 gph (0.76lph), 0.1gph (0.38lph),
or None (default is 3.0 gph (11.3lph).
Low Pressure Shutoff
If a low pressure is detected during dispense, the Low Pressure Alarm is
triggered. The dispenser also halts dispensing if this field is enabled and the
pressure is less than the
Low Pressure Shutoff Value field below.
Allowable selections: Disabled, Enabled (default is Disabled).
Low Pressure Shutoff Value
If a low pressure is detected during dispense, a low pressure alarm is trig-
gered. The dispenser also halts dispensing if the pressure is lower than the
value in this field.
Allowable selections: 0 to 25 psi (0 to 172kPa)
Default: 0.0
Continuous Handle Timeout
If the dispenser handle remains off the hook for the period of time entered in
this field, the line is shut down by the console.
Allowable selections: 1 to 16 hours. Default: 16 hours
Fuel Out Limit
If the tank product level is below the limit entered in this field, the Fuel Out
Alarm is triggered.
Allowable selections: 0.00 to 15.00 in (0.00 to 381.00mm). Default: 10.00 in
(254mm).
Altitude Pressure Offset
Allows you to set an altitude pressure adjustment for the absolute pressure
transducer of plus or minus 5psi.
Allowable selections: -5.0 to 5.0. Default: 0.0.
