4.0 Information Screens
Ver-Mac - May 2011 1210 QuickStep Programming User Manual, Ver 5.0 5
Status Indicators
NORMAL
Message board is operating under ideal conditions.
Batteries charged beyond the low battery threshold.
LOW BAT
Battery voltage is getting low and unit needs to be
charged.
Voltage below 11.5V. Recharge batteries as soon as
possible.
SIGN OFF
Sign voltage has reached critical discharge threshold
(10.5V). The sign has been powered down to minimize
damage to batteries.
Note: If sun conditions are favorable, the solar panels
continue to recharge the batteries. The supplied voltage
may not be sufficient to reach the threshold for a return
to normal operation (12.6V).
(see Maintenance Manual: Charging Batteries for in-depth
explanation)
REG DEFECT
Communication with solar regulator has been lost.
Possible regulator defect, or loose/broken data cable.
ERR L#
Display has an error. Message board (sign) is dark with
no message display.
Note: Indicates the line location of the fault, example: L2
(line two). You should do a visual check of the display
panel.
RADAR ERR
PCMS is not receiving data from radar device.
Possible causes: no radar, no power to radar, or radar
defect.
SIGN DOWN
Sign is incorrectly configured as a truck mount unit. (see
Section 6.3 Config.)
Table 3 – Status Indicators
