6.0 Utilities
Ver-Mac - May 2011 1210 QuickStep Programming User Manual, Ver 5.0 33
6.2.2 Beacons
[ ] Enter > Main Menu > [F4] Utilities > [F2] Config > [] Next Page > [F3] Beacons
Beacons are an optional component on the PCMS-1210 QS unit.
STATUS (PRESENT/NOT PRESENT): indicates whether the PCMS unit is
equipped with the optional Beacon Control Module.
Key Function
Toggles between SELECTED and OFF.
[F2]
Toggles the beacon pattern: Full, Sides or Up/Down
• Full–flashes all 4 beacons at once
• Sides–flashes the left side, followed by the right
• Up/Down–flashes the top, followed by the bottom
[]
Increases or decreases the flashing speed of the
beacons by 10 cycle intervals (Min. 60 cycles/minute,
Max. 120 cycles/minute).
Table 14 – Beacons Configuration Menu
