4.0 Information Screens
6 1210 QuickStep Programming User Manual, Ver 5.0 Ver-Mac - May 2011
4.2 System Information
[]
Figure 3 – System Information
This screen displays real-time system information from various sources:
• BAT: the number of amps to run the sign and current battery voltage
• SOL: number of amps feeding into the batteries from the solar panels
• RADAR: current operating state (ON / OFF)
• SPD: real-time captured speed and unit of measurement of speed
(MPH/KMH)
Note:
Truck-mount units have no solar regulator and so only voltage readings are
displayed.
