MCV330 (2) + LIEBERT® ECONOPHASE (2) + BASE ASSEMBLY
Form No.: DPN001040_REV4
COMPONENT LOCATION DIAGRAM
HEAT REJECTION SKID
1
3
6
5
7
8
1. MCV330 Electric Panel System 1
2. MCV330 Electric Panel System 2
3. Coils
4. EC Fans
5. Liebert® ECONOPHASE- System 1
6. Liebert® ECONOPHASE- System 2
7. High voltage customer connection System 1
8. High voltage customer connection System 2
9. Low voltage customer connection System 1
10. Low voltage customer connection System 2
11. Piping connections Systems 1&2
S
y
s
t
e
m
2
4
S
y
s
t
e
m
1
Front
Note:
1. Electrical connections for entire assembly are located
in high voltage customer connection boxes (items 7 & 8)
and low voltage customer connection box (item 9 & 10).
2. Piping connections for entire assembly are in one
location (item 11).
Back
2
9
10
11
