Vertiv Liebert MCV440 - DPN004259

REV : 5
REV DATE : 1/22
DPN004259
Page :1 /2
LIEBERT® MCV MCV440 + LIEBERT® ECONOPHASE + BASE ASSEMBLY
Form No.: DPN001040_REV4
CABINET & ANCHOR DIMENSIONAL DATA
LIEBERT® HEAT REJECTION SKID
NOTES:
1) Minimum clearance on the Main Unit Disconnect Enclosure shall be 48" (1219mm) or per local code.
2) Recommended minimum 48" (1219mm) clearance when multiple skids are mounted side by side to ensure proper airflow. Contact the factory for other spacing requirements.
Main
Electrical
Box
End
101 1/4"
2572mm
175"
4436mm
111"
2819mm
Model
Domestic Shipping Weight
lb. (kg)
Export Shipping Weight
lb. (kg)
MCV440 Single Skid
with Receiver
MCV440 Single Skid
without Receiver
5900 (2676) 6140 (2785)
5800 (2630) 6040 (2740)
