REV : A
REV DATE : 3/22
10032070
Page :2 /2
LIEBERT® MCV430 + LIEBERT® ECONOPHASE + BASE ASSEMBLY
Form No.: DPN001040_REV4
CABINET & ANCHOR DIMENSIONAL DATA
LIEBERT® HEAT REJECTION SKID
NOTES:
1) Underside of unit, coil and fan removed for clarity.
2) Four mounting holes and four 3/4" field supplied bolts required to secure skid base assembly to customer support structure. Bolt grade to be specified by local requirements.
Underside of Unit
Coil and Fans removed for clarity
101 1/4"
2572mm
132 1/4"
3360mm
75 1/4"
1912mm
Main
Electrical
Box
End
106 1/4"
2698mm
A
DETAIL A
TYP. (4) PLACES
20"
508mm
20"
508mm
13"
330mm
13"
330mm
1 5/8"
42mm
1 5/8"
42mm
O
1"
25mm
(8) Mounting Holes
(Contact Points)
O
3/4"
19mm
(8) Weep Holes
Ref.
