Installation
Table 2-3 shows a clear image of all the components that constitute the automatic door mechanism.
Table 2-3 Automatic Door parts
No. Part Name Icon Quantity Remark
1 Motor 1
2 Driven wheel 1
3 Hanger device 4
4 Belt fixture 1
5
Double door belt
fixture
1
6 Leather belt 1
7 Brake 2
8 Power Supply 1
9 Controller 1
10 Safety light sensor 1
