Chapter 9 Transferring the 6000A V2 Platform Interface
Establishing connection
User Manual 76100000200 Rev. 001 65
Permanent Mode the Remote screen function is still active when
the
6000A V2 Platform is switched off and
restarted.
Permanent with password same function as the Permanent mode,
with an access to the equipment via VNC
protected by a password: 42000
The password to access VNC can be modified:
1 Click on the menu key Change password.
2 Enter the current password in the Edition keypad and press Enter to
validate.
3 Enter the new password and press Enter to validate.
Ethernet > Mode
Parameters of the local Ethernet network to which the 6000A V2 Platform
is connected:
Config 1 to 4 static mode enabling input of the configuration of
4 sites. If this parameter is selected, the following
parameters must be entered:
– Site Name the user can enter the name of the site in the Edit
menu.
– IP Address IP address of the 6000A V2 Platform
– IP Mask address of the mask of the sub-network
– IP Gateway IP address of the machine enabling access
outside the sub-network.
– DNS
1
IP address of the machine providing the IP
address on the basis of the name
– Domain name name of the local network to which the 6000A V2
Platform is connected.
Dynamic in this mode, which requires a DHCP server, the
6000A V2 Platform requests an IP address from
this server which will be allocated dynamically if
dynamic host configuration is activated on the
local network.
After selecting this mode or after power-on, the
6000A V2 Platform tries to establish a connection
to obtain an address from a DHCP server. If for
any reason, this process fails, the 6000A V2
Platform reverses to static IP address mode with
User1 IP address.
1.Domain Name Server
