VIBROBIT MK40 User Manual

ВШПА.421412.304 И1 SCIENTIFIC-PRODUCTION ENTERPRISE VIBROBIT LLC
Measuring channel input calibration
Measuring channel input calibration sequence is simple enough:
1. Indicate measuring channel current range value (RangeCurrMin, RangeCurrMax);
2. Indicate measured parameter range (RangeParamMin, RangeParamMax);
3. Set 20% of RangeCurrMax current at channel input;
4. Rewrite AdcData value to AdcInMin;
5. Set RangeCurrMax current at channel input;
6. Rewrite AdcData value to AdcInMax;
7. Transfer calibration results to MK40 Module;
8. Implement ratios recalculation.
Alteration of measured parameter range consists in alteration of RangeParamMin, RangeParamMax
parameters.
Calibration wizard is provided in dedicated MK40 Module setting software, which considerably simplifies
calibration process.
Standard output calibration
By measured parameter, standard output range corresponds to input range (RangeParamMin,
RangeParamMax). Standard output calibration consists of the following steps:
1. Indicate standard output current range value (CurrOutMin, CurrOutMax);
2. By writing of value to DacDirectData select current (by means of microammeter), equal to 20% of
CurrOutMax, at standard output;
3. Rewrite DacDirectData value to DacOutMin;
4. By writing of value to DacDirectData select current (by means of microammeter), equal to
CurrOutMax, at standard output;
5. Rewrite DacDirectData value to DacOutMax;
6. Write zero to DacDirectData (switch on calibration mode);
7. Transfer calibration results to MK40 Module;
8. Implement ratios recalculation.
Alteration of input measured parameter range (RangeParamMin, RangeParamMax) automatically changes
parameter range at standard output. Calibration wizard is provided in MK40 setup software for module calibration,
which considerably simplifies calibration process.
Note. Writing of calibration results to MK40 Module and recalculation of ratios can be carried out once after all
calibration steps (input, standard output) are completed.
No revisions 19
