Module MK40 Setup Manual
ВШПА.421412.304 И1
Module parameters
For module parameters setup, act as follows:
•
Set logic alarm disabling period after resetting (discreteness – 0.5s);
•
Set set-points disabling period after measuring channel normalization (discreteness – 0.5s);
•
Set set-points test timeout after sensor resetting (discreteness – 0.5s);
•
Set stop mode test timeout (discreteness – 0.5s);
•
Set measurements clock cycle;
•
Set measurements period for both channels (discreteness – 0.1s).
Logic outputs inversion
For each logic output (except for output 6) select, whether to implement signal inversion or not.
Program close-down
On completion of MK10 required parameters entry, parameters must be written to the module, for which, select
Write parameters to module in Actions Menu or press push button.
For parameters saving to MK10 volatile memory, select Save actual setting to memory command or press
push button.
Selection of Parameters comparison command in Actions Menu is recommended to compare settings, saved
to module memory and setting in PC setup software; test report on comparison results will be displayed.
Next, select Disconnect command in Connection Menu or press push button.
On setup completion, text report must be generated. For this, select Text report command in File menu .
40
