VIBROBIT MK40 - Table 17. List of RS485 Interface Registers; Table 18. List of CAN2.0 B Interface Registers

ВШПА.421412.304 И1 SCIENTIFIC-PRODUCTION ENTERPRISE VIBROBIT LLC
Communication interfaces
Table 17. List of RS485 interface registers
Name Label
Type
(byte)
Address
(Hex)
Default
value
Notes
Interface operation enabling:
(not 0 – interface enabled)
Enabled
Uchar (1) 0x0F00 0
Operating parameters change by commands and via RS485
interface:
(not 0 –enabled)
ChangeData
Uchar (1) 0x0F01 0
Single write operation:
(not 0 –enabled)
OneWrite
Uchar (1) 0x0F02 0
Unit address on RS485 bus (from 1 to 247)
Address
Uchar (1) 0x0F03 1
Data rate, bit/s:
0 – 4800; 1 – 9600; 2 – 19200; 3 – 38400;
4 – 57600; 5 – 115200; 6 – 230400
Speed
Uchar (1) 0x0F04 0
Note. RS485 interface parameters come into effect only after the module re-initialization.
Table 18. List of CAN2.0B interface registers
Name Label
Type
(byte)
Address
(Hex)
Default
value
Notes
Interface operation enabling
(not 0 – interface enabled)
Enabled
Uchar (1) 0x1000 0
Data rate, bit/s:
0 – 1000; 1 – 500; 2 – 250; 3 – 200; 4 – 125;
5 – 100; 6 – 80; 7 - 40
Speed
Uchar (1) 0x1001 0
Unit address on the bus
BasicAddress
Uint (2) 0x1002 0
Message sending interval by 0. 5s
BasicTime
Uchar (1) 0x1004 0
Data sending in channel 1
bit 0 – measurement results
bit 1 – combined message
bits 2-7 – reserved, must be equal to 0
BasicDataOut_1
Uchar (1) 0x1005 0 1
Data sending in channel 2
bit 0 – measurement results
bits 1-7 – reserved, must be equal to 0
BasicDataOut_2
Uchar (1) 0x1006 0
Notes:
1. Implemented in module software version 3.40 and newer.
2. Default value – value assigned to parameter after the module cold start.
3. CAN2.0B interface parameters come into effect only after the module re-initialization.
No revisions 29
