VIBROBIT MK40 User Manual
4
of 1
of 1 rating
51 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
S9 bridge – Ch
annel 2 oper
ating mode sel
ection
Position
Mode
OFF
Standard o
perating m
ode
ON
+24V module suppl
y voltage m
onitoring
Note. In supply voltage monitoring mode S13bridge
must be OFF
, S2 bridge must be in 1-2 position.
46
No revisions
45
47
Table of Contents
Table of Contents
3
General Information
4
Technical Specifications
5
Table 1. Technical Specifications of MK40 Module
5
Table 2. Additional Specifications of MK40 Module
6
Indication and Control Equipment
7
Module Operation
10
Switching Power on
10
Resetting
10
Parameters Measurement
12
Table 3. Set-Points Operating Modes
15
Table 4. 2Nd Channel Recommended Parameters for Module Supply Voltage Measurement
16
Calibration Recommendations
18
Table 6. Module Status Flags Statussys and Their Position if Logic Outputs Matrix Logicmatrix
20
Logic Outputs
20
Table 5. Measuring Channels Status Flags Statusch and Their Position if Logic Outputs Matrix Logicmatrix
20
Digital Control Interfaces
21
RS485 Interface
21
Table 7. RS485 Interface Parameters
21
Table 8. Possible Modbus Protocol Error Codes
22
Table 9. Implemented Modbus Protocol Commands in MK40 Module
22
Table 10. List of Modbus Protocol Supported Diagnostic Commands
23
CAN2.0B Interface
24
Table 11. CAN2.0B Interface Parameters
24
I2C Driven Interface
25
Table 12. I2C Driven Interface Parameters
25
Table 13. List of Measuring Channels Calibration Parameters
26
Module Settings and Current State (Address Tables)
26
Table 14. List of Measuring Channels Basic Registers
27
Table 15. List of Standard Output Control Registers
27
Table 16.List of System Registers
28
Table 17. List of RS485 Interface Registers
29
Table 18. List of CAN2.0B Interface Registers
29
Table 19. List of CAN2.0B Interface Additional Registers
30
Table 20. List of Module Identification Information Registers
31
Table 21. List of Module Software Identification Information Registers
31
Table 22. List of Measurement Results Registers
31
Table 23. List of Control Registers
32
Software
33
Getting Started
34
Measuring Channels Parameters
34
Calibration
36
Communication Interfaces Parameters
37
General Parameters
39
Program Close-Down
40
Program Menu Description
41
Maintenance
45
Handling and Storage
45
Manufacturer's Warranty
45
Annexes
46
А. Controls Arrangement on MK40 Module Board
46
Connector Terminals Assignment
48
Table 24. MK40 Module X4 Connector Terminals Assignment
48
Module Labeling
49
Module (Setup) Order Form Example
50
List of Tables
51
