VIBROBIT MK40 User Manual

ВШПА.421412.304 И1 SCIENTIFIC-PRODUCTION ENTERPRISE VIBROBIT LLC
Technical specifications
Table 1. Technical specifications of MK40 Module
Parameter name Value
Number of measuring channels 2
Measuring range and rotor speed alarm, rotations per minute 1 – 10 000
Measuring ranges and input signal alarm:
- Direct current, mA
- DC voltage, V
1-5; 4-20
0.95-4.75
Input resistance, Ohm
- Direct current
- DC voltage
953±2; 232±0,5
not less than 10000
Acceptable tolerance limits of standard output mean percentage error of rotor speed
measuring channels, %
±1,0
Acceptable tolerance limits of digital display mean absolute error of rotor speed measuring
channels, rotations per minute, not greater than
±2,0
Readings updating time, s 0.1 – 1.0
Number of standard DC current signals 2
Output standard DC current signal, mA 0-5;4-20
Output standard DC current signal load resistance, Ohm, not greater than 2000; 500
Number of set-points for each measuring channel 3
Number of digital outputs 6
Output digital signals
- type
- DC voltage, V, not greater than
- output current, mA, not greater than
open collector
24
100
Number of synchronization outputs 2
Output synchronization signals
- type
- DC voltage, V, not greater than
- output current, mA, not greater than
open collector
24
100
Supported digital communication interfaces types RS485 (ModBus)
CAN2.0B
Diagnostic I2C
Power supply voltage, V
- for MK40-AC option
- for MK40-DC options
AC 50Hz 176-242
DC 246-350
+(24±1)
Power consumption, W, not greater than 7
⁰Operating ambient temperature range (inside and out), C +5-+45
No revisions 5
