Module MK40 Setup Manual ВШПА.421412.304 И1
Module settings and current state (address tables)
Module measuring channels parameters and system settings
Table 13. List of measuring channels calibration parameters
Name Label
Type
(byte)
Address (Hex)
Channel
1
Channel
2
Default
value
Note
Sensor current range lower level
RangeCurrMin
Float (4) 0x0600 0x0700 1.0
Sensor current range higher level
RangeCurrMax
Float (4) 0x0604 0x0704 5.0
Sensor lower limit test enabling
EnaValidMin
Uchar (1) 0x0608 0x0708 1
Sensor higher limit test enabling
EnaValidMax
Uchar (1) 0x0609 0x0709 1
Sensor current lower tolerance limit
CurrValidMin
Float (4) 0x060A 0x070A 0.7
Sensor current upper tolerance limit
CurrValidMax
Float (4) 0x060E 0x070E 5.3
Sensor test hysteresis
CurrValidHist
Float (4) 0x0612 0x0712 0.1
Standard output current range lower level
CurrOutMin
Float (4) 0x0616 0x0716 4.0
Standard output current range higher level
CurrOutMax
Float (4) 0x061A 0x071A 20.0
ADC value of sensor current calibration lower level
AdcInMin
Uint (2) 0x061E 0x071E 0 1
ADC value of sensor current calibration higher
level
AdcInMax
Uint (2) 0x0620 0x0720 0 1
DAC value of standard output calibration lower
level
DacOutMin
Uint (2) 0x0622 0x0722 0 1
DAC value of standard output calibration higher
level
DacOutMax
Uint (2) 0x0624 0x0724 0 1
Notes:
1. Calibration data is missing, all measuring parameters will be equal to zero.
2. Default value – value assigned to parameter after the module cold start.
26 No revisions
