Module MK40 Setup Manual

ВШПА.421412.304 И1

For reading settings from the module, select Read interfaces settings from module option. This option is

active when MK40 is connected.

For writing settings to the module, select Write interface settings to module option in shortcut menu. This

option is active when MK40 is connected and logic outputs are disabled.

For saving RS485 and CAN2.0B interfaces settings, written to the module, to volatile memory, select relevant

Saving settings to memory menu option. This option is active when MK40 is connected and logic outputs are

disabled.

For RS485 interface re-initialization in case of settings change, select RS485 initialization option in shortcut

menu. This option is active when MK40 is connected and logic outputs are disabled.

RS485 Interface

For interface parameters setup, act as follows:

•

Enable/disable interface operation by selecting/deselecting RS485 Interface option check box;

•

Enable/disable interface operating parameters setup;

•

Switch on/off single write command support;

•

Select one of possible interface data rates;

•

Set module address on interface bus (acceptable address range: 1÷247).

CAN2.0B Interface

For interface parameters setup, act as follows:

•

Enable/disable interface operation by selecting/deselecting CAN2.0B5 Interface option check box;

•

Set message sending interval (discreteness – 0.5s);

•

Select one of possible interface data rates;

•

Set module address on interface bus (acceptable address range 0÷255);

•

Enable/disable data transfer in channels.
