76
Maintenance
> Take the bolts previously removed and fit them as shown to both
sides of the machine.
> Check that the protection is secured so that it cannot drop.
N
OTE
!
This ensures that the protection is secured so that it will not drop and
strike anyone during maintenance, cleaning or servicing work on the
rotor.
> Check the conditioner for loose fingers.
> Check the lock plate by the bolt.
> Use an appropriate wrench to tighten up the bolt.
→ »Torque moment« Page 97.
N
OTE
!
The Y-fingers should be able to move freely.
Left-hand side
Right-hand side
Lock plate
Bolt
Y-fingers
Rotor
