22
Preparation
Preparation
Preparing the ma-
chine
For transporting the user the machine is divided into main compo-
nents. The machine is assembled according to the specific assembly
instructions delivered with each machine.
The following chapter is for initial assembling, reducing the length of
the P.T.O. shaft, etc. When assembling after, only certain attachment
points should be carried out.
Initial connection of the machine
Exercise caution when a new machine is connected for the first time.
Make sure that all safety instructions are complied with.
Attention to the safety instructions will increase your personal safety.
Failure to follow the safety instructions may result in serious injuries
and accidents.
Crane lifting safety
Only use approved lifting equipment
Only use approved lifting equipment which is correctly fastened to the
machine.
This will improve your personal safety.
Failure to follow the safety instructions may result in serious injuries
and accidents.
If you wish to move the machine, crane equipment must be used. The
machine is lifted in the following way:
> Connect the double-acting hydraulic system of the machine to the
tractor.
> Carefully activate the tractor's double-acting hydraulic outlet so
that the suspension turns in over the machine.
• When the machine's suspension is over the machine, deactivate
the tractor's hydraulic outlet.
> Disconnect the machine's hydraulic system from the tractor.
> Attach approved lifting equipment to the 2 areas shown on the ma-
chine.
> Carefully lift the machine off the ground and move it to the desired
position.
Unladen weight of the machine:
→ »Machine specification« Page 21.
33.502.000
