Assembly - attachment
29
Hydraulic
Safety
Only connect hydraulics when the system is not pressurised
You should only connect the hydraulic hoses to the tractor's hydraulics
when the hydraulic system on both tractor and machine is depressu-
rised.
There is a risk that the machine will move unintentionally.
Unintentional movement of the machine may result in serious injuries.
Avoid mixing oil
Avoid using different tractors for the same machine.
It can lead to illegal mixing of various oil types.
Illegal mixing of various oil types can damage the hydraulic system of
the tractor.
The hydraulic system should be checked regularly
All hoses and fittings should be checked regularly for visual damage.
Hydraulic hoses also age without visual damage.
Defect hydraulic hoses can result in personal injury or fire.
Colour marking of the hydraulic connections
The hydraulic connections between the tractor and the machine must
be colour marked.
By colour marking the hydraulic connections you avoid wrong opera-
tion of the machine.
Incorrect operation or unintentional movement of the machine may re-
sult in serious injuries.
Connecting hydraulics
When connecting the hydraulics there is an increased risk of personal
injuries. Attention to the above instruction points will protect you and
others from injury.
Failure to follow these instructions may result in serious injuries.
When attaching hydraulics, make sure that the tractor is fitted, as a
minimum, with:
• A set of double-acting hydraulic outlets.
• A single-acting hydraulic outlet.
Securing the hydraulics in transport position
The tractor hydraulic system must not be activated unintentionally in
transport position.
Unintentional activation of the tractor hydraulic system can result in
unforeseen movement.
Unforeseen movement can result in personal injuries.
