Violin Memory 6000 Series - Parts and Accessory List; Installation Tools and Equipment

Chapter 1: Memory Array Hardware Installation
8
Violin 6000 Series Memory Array Installation Guide 535-0045-00 Rev 02
Parts and Accessory List
The table below lists the parts that may be included in the Memory Array shipping package.
Contents vary depending on the system ordered. Some optional accessories are not listed here.
Installation Tools and Equipment
The table below lists the tools and equipment used during the installation process:
Item
Number
Part Description Quantity
1 Memory Array 1
2 Flash VIMMs (preinstalled in Memory Array) 24, 44 or 64
3 C14-C19 Connector AC power supply cable, 6 ft, in Accessory
Box; connects to C20 inlets on the rear of the chassis.
2
4 DB9 to RJ-45, 6 ft rollover console cable, in Accessory Box 2
5 Rail Mounting Kit, includes two flat head screws, cage nuts and
screws
1
6 Rack ears 2
7 Host Bus Adapter (HBA) blanking panels (installed if direct-
attached system)
4
8 PCIe card (if direct-attached system ordered) 4
9 PCIe cable, 3 m, in Accessory Box (if PCIe cards ordered)
PCIe cable, 3 m (if a vMOS-6 system)
4
1
Table 1.2 Parts List
Item
Number
Tool Quantity
1 Phillips head screwdrivers, sizes 1 and 2 1 each
2 Computer system for direct connect configuration 1 or 2
3 CAT 5 Ethernet Cable with RJ-45 connectors, straight-
through or cross-over, depending on your installation
2
Table 1.3 Required Installation Tools
