Fibre Channel Adapter Card Specifications
535-0045-00 Rev 02 Violin 6000 Series Memory Array Installation Guide 63
Fibre Channel Adapter Card Specifications
The following table provides basic information for the QLogic QLE2562 Host Bus Adapter. See the
QLogic Web site (http://www.qlogic.com) for the most complete and up-to-date information.
The following table is a description of the LED states of the QLogic QLE2562 Host Bus Adapter.
See the QLogic Web site (http://www.qlogic.com) for the most complete and up-to-date information.
Fibre Channel Specifications
Negotiation:
IOPS:
Class of service:
Topology:
Protocols:
8/4/2Gbps auto-negotiation
200,000 initiator and target IOPS per port
2 and 3
FC-AL, FC-AL2, point-to-point, switched fabric
FCP-3-SCSI
FC-Tape (FCP-2)
PCIe Express Interface
Compliance:
Physical and Electrical:
PCIe Express Base Specification rev. 2.0
PCIe Express Card Electromechanical Specification rev. 2.0
PCIe Bus Power Management Interface Specification rev. 1.2
PCI Hot Plug Specification rev. 1.0
PCIe x8 physical connector
StarPoint link training:
- Maximum x4 lanes for Gen2 rate
- Maximum x8 lanes for Gen1 rate
Connectivity
Ports: Dual 8Gbps Fibre Channel
SFP+ with LC-style connector
HBA Specifications
Airflow:
Power consumption:
Form factor:
Temperature:
Relative Humidity:
RoHS compliance:
No airflow required
6.2 Watts (typical)
Low-profile PCI Express card (6.6 in. x 2.54 in.)
0 to 55°C (operating)
-40 to 70°C (non-operating)
10% to 90% (operating, non-condensing)
5% to 93% (non-operating, non-condensing)
RoHS 6
Table G.2 Fibre Channel HBA Specifications
Yel l ow
(8Gbps)
Green
(4Gbps)
Orange
(2Gbps)
Description
Off Off Off Power off
On On On Power on (before firmware initialization)
Flashing Flashing Flashing Power on (after firmware initialization)
Yellow, Green and Amber flashing alternatively Firmware error
Off Off On/Flashing Online, 2Gbps link/I/O activity
Off On/Flashing Off Online, 4Gbps link/I/O activity
On/Flashing Off Off Online, 8Gbps link/I/O activity
Table G.3 LED Descriptions
