System Specifications
62 Violin 6000 Series Memory Array Installation Guide 535-0045-00 Rev 02
Memory Array System Specifications
The table below lists the system specifications for all Violin 6000 Series Memory Array models. See
http://www.violin-memory.com for the most up-to-date specifications.
*Nominal power measurements for Fibre Channel configuration.
Series 6600 6200
Model 6606 6611 6616 6212 6222 6232
Flash Type SLC MLC
Raw Capacity (GiB/GB) 6TB/6.6TB 11TB/12.1TB 16TB/17.6TB 12TB/13.2TB 22TB/24.2TB 32TB/35.2TB
VIMM Count
(Data + Hot Spare)
20 + 4 40 + 4 60 + 4 20 + 4 40.4 60 + 4
Reliability/Resiliency System Level Hardware Based vRAID
4 vRAID Controller Modules
2 Array Controller Modules
2 Memory Gateways
Automated Failover & Failback
Connectivity Options 8x 4/8Gb/s Fibre Channel
8x 10GbE iSCSI
8x 40Gb/s QDR InfiniBand
4x PCIe Gen2 x8
Dimensions
Height:
Width:
Depth:
Cable Management:
5.25" (3RU/134 mm)
17.5” / 420 mm
27” / 700 mm
6” / 153 mm
Minimum Rear
Clearance
7" (178 mm)
Weight 76lbs/34.5kg 89lbs/40.4kg 76lbs/34.5kg 89lbs/40.4kg
Power* 1119W 1693W 1355W 1723W
Cooling 3822 BTU/hr 5780 BTU/hr 4626 BTU/hr 5884 BTU/hr
Environmental
Inlet Temp:
Humidity:
Altitude:
0°C to 40°C
5-95% (non condensing)
10,000 feet (Derate temperature)
Electrical
Input Power Voltage:
Operating Range:
Current Rating:
200-240 VAC
180-264 VAC
15 A maximum
2100VA max.
Interfaces RJ-45 Serial Console (2)
RJ-45 10/100/1000 Ethernet (2)
Management (CLI) Serial, SSH, SNMP, Web/HTTP
Table G.1 Memory Array System Specifications
