System Verification and Management
535-0045-00 Rev 02
Violin 6000 Series Memory Array Installation Guide 39
Without the brief option, the show cluster global command displays additional information
about each node in the cluster. Instead of using an asterisk to designate the local node ID, this
display uses the label <--- (local node).
Example of show cluster global:
Configuring the PCIe Connection
If the Violin 6000 Memory Array is set up in a direct-attached configuration using PCIe cables, you
must configure the PCIe connection using the CLI. Use the show pcie command to display the
PCIe connection information.
Note: It is unnecessary to modify the PCIe configuration for Memory Arrays with internal Memory
Gateways. The PCIe configuration is already set at the factory.
Follow these steps to access the pcie command and configure the PCIe connection.
1. Start a terminal application and enter the host name of the Memory Array or the ACM
Management IP address (assigned during initial configuration).
violin-acma [violin: master] (config) # show cluster global
Cluster ID: 15000-0000-0016
Cluster name: violin
Management IP: 10.1.2.345/22
Cluster master IF: eth1
Cluster node count: 2
Node Status:
Node ID: 1 <--- (local node)
Host ID: 219dc7a368b5
Hostname: violin-acma-acm-a
Node Role: master
Node State: online
Node internal address: 169.254.1.10, port: 60102
Node external address: 10.1.10.57
Recv. Heartbeats from: 2
Send Heartbeats to: 2
Node Status:
Node ID: 2
Host ID: e18b8f130daf
Hostname: violin-acmb
Node Role: standby
Node State: online
Node internal address: 169.254.1.11, port: 57575
Node external address: 10.1.9.208
Recv. Heartbeats from: 1
Send Heartbeats to: 1
violin-acma-acm-a [violin: master] (config) #█
