7.4.2.7 Set Time-Based Recording Burst Count Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x000F 0x02 0x0006 Used Ignored
0x00
Byte 8:
Group number
Multiple groups can be
specified by logically ORing
the values:
0x01 Group A
0x02 Group B
0x04 Group C
0x08 Group D
Bytes 9-116:
64-bit burst count, in scans.
Note, the most significant 3
bytes will be ignored and
should be 0x000000.
This value specifies the number of recordings the specified cards will collect during each recording burst
Range: 0 to 1099511627775
Default: 0
7.4.2.8 Set Time-Based Recording Burst Skip Count Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x000F 0x02 0x0007 Used Ignored
0x00
Byte 8:
Group number
Multiple groups can be
specified by logically ORing
the values:
0x01 Group A
0x02 Group B
0x04 Group C
0x08 Group D
Bytes 9-16:
64-bit burst skip count, in
scans. The most significant 3
bytes will be ignored and
should be 0x000000.
The time-based recording burst skip count instructs the specified cards to skip the specified number of
scans between recording bursts.
Range: 0 to 1099511627775
Default: 0
