7.4.3 Scan Group
Scan Group commands are only available while the system is idle.
7.4.3.1 Set Scan Rate Command
Length Command
Group
Command
Code
Card
Mask
Channel
Mask
Parameters
0x000B 0x03 0x0001 Used Ignored
0x00
Bytes 8-11:
32-bit scan rate in
samples/second. Valid values
are
Radix
10
Radix
2
2000 2048
1000 1024
500 512
200 256
100 128
10 128
Byte 12:
Radix. Valid values are 2 or
10
This function sets the scanning rate of the system.
Default: 1000, radix 10
7.4.3.2 Create Scan List Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0007 0x03 0x0002 Used Ignored
Byte 8:
Channel Mask
This command determines which channels are enabled within the selected cards. The channel mask
should be a value between 0b00000001 and 0b11111111, where the least significant bit corresponds to
channel 1 and the most significant bit corresponds to channel 8.
Default: 0b00000000
