Vishay 7000 - Clear Errors; System Status Query; Get Error Message from Error Code

Vishay Micro-Measurements System 7000 Programmer’s Reference Manual
Page 141 of 142
7.4.8.11 Clear Errors
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0006 0x08 0x0009 Used Ignored
0x00
None.
Clears the error flags and status on the specified cards and on the control module.. Does not delete the
Error.Log files.
7.4.8.12 System Status Query
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0006 0x08 0x800C
Query Only
Ignored
0x00
Ignored
0x00
none
Returns the system status from the Control Module
Byte 8-9: System State
0x0001 = idle
0x0002 = uploading
0x0004 = Armed
0x0008 = Scanning
0x0010 = Calibrating
0x0020 = Downloading
0x0040 = Updating
0x0080 = Maintenance Mode
Byte 10: Error Flag 0 = no error, 1 = error
Byte 11: Last Error Code, if Error Flag =1
7.4.8.13 Get Error Message from Error Code
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0006 0x08 0x800F
Query Only
Ignored
0x00
Ignored
0x00
Byte 8:
Error Code In
Returns a null-terminated (0x00) text string containing a descriptor for the entered error code.
