7.4.2.11 Set Limits-Based Recording Skip Count Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x000F 0x02 0x000A Used Ignored
0x00
Byte 8:
Group number
Multiple groups can be
specified by logically ORing
the values:
0x01 Group A
0x02 Group B
0x04 Group C
0x08 Group D
Bytes 9-16:
64-bit skip count, in scans.
The most significant 3 bytes
will be ignored and should be
0x000000.
Determines the number of scans to skip while using limits-based recording. A skip factor of 1 will skip
every other point (decimation factor of 2). Specifying a 0 indicates that no scans will be skipped.
Range: 0 to 1099511627775
Default: 0
7.4.2.12 Set Limits-Based Recording Burst Count Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x000F 0x02 0x000B Used Ignored
0x00
Byte 8:
Group number
Multiple groups can be
specified by logically ORing
the values:
0x01 Group A
0x02 Group B
0x04 Group C
0x08 Group D
Bytes 9-16:
64-bit burst count, in scans.
Note, the most significant 3
bytes will be ignored and
should be 0x000000.
This value specifies the number of recordings the specified cards will collect during each recording burst.
Range: 0 to 1099511627775
Default: 0
