Vishay Micro-Measurements System 7000 Programmer’s Reference Manual
Page 138 of 142
7.4.8.4 Configure Online Data
Length
Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0018 0x08 0x0005
Ignored
0x0000
Ignored
0x00
Bytes 8-9:
Skip Count
Bytes 10-25
For each card a mask
indicating which channel data
to transmit
You should fill in a mask for a total of 16 cards. This is true even if slots are empty or if you have a 4-
slot scanner.) Byte 10 is used for the card in slot 1; byte 25 is used for the card in slot 16.
Fill in the channel mask, where channel 1 is represented in the least-significant bit, and channel 8 is
represented in the most-significant bit.
7 6 5 4 3 2 1 0 Bit
8 7 6 5 4 3 2 1 Channel (1=include in offline data, 0 =
exclude from offline data)
Skip Count
Range 0 to 32768
Default: 0 scans (don't skip)
7.4.8.5 Define Scanner’s Network Configuration
Length
Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0007 0x08 0x000D
Ignored
0x0000
Ignored
0x00
Byte 8
0x00 – The scanner is not a
member of a network
(default)
0x01 - Scanner is a member
of a network and it is the
master
0x02 –Scanner is a member
of a network, but it is not the
master
