3.14.2.6 Examples
Example 1
You are scanning at 1000 samples/second and have 2 channels in Channel Group A recorded at 1000
samples/second. The first recorded scan is always recorded with absolute data, to be an initial point of
reference. Notice that the Scan ID and channel data are in little-endian format.
Recorded Data (in hex) Scan
ID
Chan 1
Value
Chan 2
Value
Description
1B01010001000000FF000000 01 1 255 16-bit absolute Scan ID, 32-bit
absolute channel data, group A
100000 02 1 255 Incremented Scan ID, relative
channel data, group A
1005FD 03 6 252 Incremented Scan ID, relative
channel data, group A (note, here,
the FD represents -3)
1900200000FC000000 05 8192 252 Incremented Scan ID, 32-bit absolute
data, group A
100201 06 8194 253 Incremented Scan ID, relative
channel data, group A
Table 19
(Red = Status Byte(s), Green = Scan ID, Blue = Channel Data)
Example 2
You are scanning at 1000 samples/second and have 2 channels in Channel Group A and 1 channel in
Group B. Group A is recording at 500 samples/second and Group B is recording at 200 samples/second.
The first recorded scan is always recorded with absolute data, to be an initial point of reference. Notice
that the Scan ID and channel data are in little-endian format.
Recorded Data (in hex) Scan
ID
Chan 1
Value
Chan 2
Value
Chan 3
Value
Description
3B01010001000000FF00000005000000 01 1 255 5 16-bit absolute Scan ID, 32-bit
absolute channel data, group
A, group B
1203000000 03 1 255 not
present
Incremented Scan ID, relative
channel data, group A
1205000100 05 2 252 not
present
Incremented Scan ID, relative
channel data, group A
22060002 06 not
present
not
present
7 Incremented Scan ID, relative
data, group B
1207000000 07 2 252 not
present
Incremented Scan ID, relative
channel data, group A
1209000000 09 2 252 not
present
Incremented Scan ID, relative
channel data, group A
320B00000000 11 2 252 7 Incremented Scan ID, relative
channel data, group A, group
B
Table 20
(Red = Status Byte(s), Green = Scan ID, Blue = Channel Data)
