4.4.3 Card Error Message
Card error messages are transmitted when a card-level error is detected. The message includes an error
code byte and a text error message.
Byte
Position
Value
1 Message Length (LSB) excluding the length bytes
2 Message Length (MSB) excluding the length bytes
3 Message Type = Error (0x02)
4 Card ID (1 through 16)
5 Channel Number (1 through 8)
6 Error Code
7 Error String Byte 0
8 Error String byte 1
… ...
9+N Error String Byte N
Table 25
4.4.4 Control Module Error Messages
Control Module error messages are transmitted when a system-level error is detected. The message
includes an error code byte and a text error message.
Byte
Position
Value
1 Message Length (LSB) excluding the length bytes
2 Message Length (MSB) excluding the length bytes
3 Message Type = Error (0x06)
4 Error Code
5 Error String byte 0
… ...
5+N Error String Byte N
Table 26
